32
Mattress
platform
sections
As standard the bed is supplied with curved platform sections. Optional
flat platform sections are available.
The four mattress platform sections (backrest, seat, thigh and calf) can
be removed by pulling them upwards off the mattress platform frame.
Lift off the calf extension sheet (1) before removing the calf section (2).
Mattress platform sections (top view)
To replace each section, make sure it is correctly positioned on the
mattress platform frame then press down firmly until it snaps into place.
Replace the calf extension sheet (1) by clipping it over the end of the
mattress platform frame.
NOTE
Do not combine flat and curved platform sections. Curved sections are lighter in colour than
the dark grey flat platform sections to help differentiate between the two types.
Head and foot
boards
The head and foot boards can be easily lifted off the bed for access to
the patient.
Underbed light
(Optional)
The underbed light illuminates the floor on either side of the bed.
The light is always on except when the bed is operating from the backup
battery.
2 1
