installation &
operating instructions
Design Envelope 4302 ivs and 4382 ivs vertical
in-line pumping unit with integrated controls
49
no. description warning alarm/trip
alarm/trip
lock
parameter reference
50 ama calibration failed ×
51 ama check U
nom
and I
nom
×
52 ama low I
nom
×
53 ama motor too big ×
54 ama motor too small ×
55 ama parameter out of range ×
56 ama interrupted by user ×
57 ama timeout ×
58 ama internal fault × ×
59 Current limit ×
60 External interlock
62 Output frequency at maximum limit ×
64 Voltage limit ×
65 Control board-over temperature × × ×
66 Heat sink temperature low ×
67 Option confi guration has changed ×
68 Safe stop activated ×
70 Illegal fc confi guration
80 Drive initialized to Default Value ×
92 No-fl ow x × Par. 22-2*
93 Dry pump × × Par. 22-2*
94 End of curve × × Par. 22-5*
95 Broken belt × × Par. 22-6*
96 Start delayed × Par. 22-7*
97 Stop delayed × Par. 22-7*
98 Clock fault × Par. 0-7*
