Page 6 of 36
Technical Data, cont.
Electronic Actuator Model Code
Model Nominal Torque
(1)
Maximum Speed (RPM)
(1)
Supply Voltage
G22 035 - 35 Nm / 310 in/lb @ 5 rpm 8 24VDC
G23 100 - 100 Nm / 885 in/lb @ 5 rpm 8 24VDC
Accessory Parts Part Number
Temperature Probes (Cable length)
CPAC0021 (350 mm) - Temperature probes with longer cable length are
available. Consult factory.
Mounting Kit F05 used on 3/4” (20 mm) and 1” (25 mm) Emech
®
valves CPMA0070
Mounting Kit F07 used on 1-1/2” (40 mm), 2” (50 mm), and 3” (75 mm)
Emech
®
valves
CPMA0071
Mounting Kit ISO F12-AR1 used on 4” (100mm) Valve CPMA0129
Power Supply D34095 (24vDC)
Blade Fuse D159969
Notes:
1. Nominal torque is the output torque at 6 rpm for G22 and 5 rpm for G23.
2. Maximum speed is the maximum recommended operating speed.
3. Contact Armstrong for special mounting kits.
Electrical Data
Power Supply Requirement 24 VDC Regulated Supply ± 10% (at the actuator terminals)
Fuse 7.5 A Blade Fuse
Analog Control Signal (Input) 4 to 20mA
Analog Feedback Signal (Output) 4 to 20mA Feedback Accuracy 0.5% (of full range)
Display 16 Character LCD with color-indicating back light
Serial Interface RS-485 (Non-isolated)
Auxiliary Sensor Input Internal Connector
Temperature Sensor Input 3 pin M8 (Female) connector
Temperature Sensor Thermistor (NTC 10kOhm @ 25°C)
Cable Gland Entry Bottom Entry
Power Spply Consumption at 24.0 Vdc
Model Current Power
G22 3.4 Amax 85 Watt
G23 4.4 Amax 115 Watt
* Exceeding motor current and speed defaults will increase current and power.
