DRV80 Disassembly
Warning!
Before disassembly observe the following:
• Isolate the electrical supply to the DRV80.
• Isolate the water supplies to the DRV80.
• Allow the hot water inlet to cool sufciently to reduce the risk of injury through contact with the hot
pipe or DRV.
4mm HEX
Step 1
Step 3
Step 4
Step 2
Failure to disconnect the
incoming power supply
before removing the plugs
may result in product
damage. Any damage
caused in this way is not
covered by the Limited
Warranty. (See back page
for full details.)
Note! Retain
Clips if
replacing
electronics
module
