Table B.2 - Pin assignment of the RJ-11 ADSL connector (end)
Contact No. Assignment
3
ADSL_RING
4
no connected
External appearance of RJ-11 with pin numbering is shown in Figure B.2.
1...4
Figure B.2 – External appearance of RJ-11 ADSL
Requirements to connection of external adaptor 12 V/48 V.
External appearance of P1J, the sizes and polarity of pins are shown in Figure B.3
Figure B.3 – External appearance, sizes and polarity of P1J
