3600 SERIES USER MANUAL
3600 Series Programmable DC Power Supply
VERSION 2.10 2006.03
7
Procedure Operation details LCD display
Step 1 Press “V-set” Input Password
Step 2
Enter the password (if the keyboard isn’t locked, please go to
step4)
Input Password
****
Step 3
Press the “OK” button, the original set value will be displayed
on the LCD. (It will return to step 2 if your password is wrong)
Set Volt = 0.000V
New=
Step 4
Enter the new voltage value with the number keypad or rotate
the dial to adjust the value
Set Volt =0.000V
New= 10V
Step 5 Press “V/A” or “mV/mA” button to confirm
Set Volt = 10.00V
New=10.00V
Step 6 Press ESC to go back to the main menu
You can exit the voltage set operation at any point by pressing the ESC key
For example, set the output voltage to 24.3V
1. Setting by number keyboard
Step1. Press “V-set” button;
Step2. Enter the password by using the number keypad (if the keypad isn’t locked, please go to step 4);
Step3. Press “OK” button (if the password is wrong, please go to step2 for reentering);
Step4. Press “2”, “4”, “.” and “3” button to enter the voltage value;
Step5. Press “V/A” button.
2. Setting by Rotary knob
(1) If the keypad isn’t locked, directly rotate the “Rotary knob”, and the voltage will be continually changed from
the previews value according to the rotation. At the beginning, the cursor will be shown on the last number of the
value which is indicated on the LCD, you can move the cursor to each number by using “ ”and “ ”buttons,
and then rotate to change the number, and let it stay at 24.3 V.
(2) If the keypad is locked
Step1. Press “V-set” button;
Step2. Enter the password by using the number keypad;
Step3. Press OK button (if the password is wrong, please go to step2 for reentering);
Step4. Rotate the Rotary knob to change the value, the operation is the same as item(1);
Step5. Press “V/A” button to confirm.
