3600 SERIES USER MANUAL
3600 Series Programmable DC Power Supply
VERSION 2.10 2006.03
26
4.14 The State Bar
Power: the power name
Add: the power address.
V: the max output voltage
A: the max output current
W: the max output power
Sending / Receiving: the communication state.
4.15 Quit the Software
Click the button to quit the software.
4.16 Use the PowerMS software control your power
Start the PowerMS program, from the Power List, select the power supply you want to use. If the desired power
does not appear on the List, use Power Setting to add it.
Click the button, ensure that the Com port, baud rate and address is the same as that of the power.
Click the button to start communication. Using the Control Mode switch, set the power in PC control mode.
You may now control the power from the computer.
In the event of communications failure, please check the Com port, baud rate and Address settings. Also ensure
that the communication cable is firmly and correctly connected.
