Array electronic 3644A User Manual

3600 SERIES USER MANUAL
3600 Series Programmable DC Power Supply
VERSION 2.10 2006.03
2
Weight 6.00kg
Dimensions 212.6mm W x 88.1mm H x 250mm D
Software
Free application software PowerMS, ActiveX control and DLL tool support VB /
VC++ / DELPHI / LABVIEW
Optional Parts
3311 isolated TTL to RS232 adaptor
3312 isolated TTL to USB adaptor
3313 isolated RS232 to RS485 adaptor
3314 isolated TTL to RS485 adaptor
Mounting rack
* 0 to 35
o
C for full rated output. At higher temperatures, the output current is derated 3% per
o
C
1.3 Features
1. LCD display with backlight.
2. High resolution measurement.
3. CC/CV mode.
4. Number keypad and rotary knob.
5. Multifunction menu.
6. Over voltage / over current protection.
7. 10 parameters storage.
8. Compact and light-weight.
9. Can be used in parallel connection.
10. Can be controlled by PC.
