3600 SERIES USER MANUAL
3600 Series Programmable DC Power Supply
VERSION 2.10 2006.03
10
2.3 Menu operation
The Menu operation offers some setting and adjusting functions. The operation and functions are as following.
Procedure Operation details LCD display
Step1 Press “ Menu ” button Input Password
Step 2
Enter the password (if the keyboard isn’t locked,
please go to step4)
Input Password
****
Step 3
Press the “OK” button (It will return to step 2 if your
password is wrong)
Max Voltage Set
Max Power Set
Step 4
The LCD displays the menu functions. Use the UP and
DOWN keys to select a function.
Max Voltage Set
Max Power Set
Rotary Knob Set
Initial Out Set
Volt. Save Set
Baud Rate Set
Address Set
Key Lock
Clear Save Date
Load Default
Exit
Step 5 Press “Enter” for confirmation
You can exit the Menu operation at any point by pressing the ESC key
2.3.1 Setting the maximum output voltage
When you select the “Max Voltage Set” function, the LCD will display:
Max Volt. = 24.00 V
New= V
Set the maximum output voltage by using the number keyboard or the
rotary knob, then press “Enter” for confirmation.
To Next Page
