ALEXA Plus
Camera Top Image Plane
Optical Center
67 mm
2.64”
54 mm
2.13”
230 mm
9.06”
332 mm
12.95”
183 mm
7.21”
180 mm
7.09”
88.8 mm
3.5”
55 mm
2.17”
38.5mm
1.52”
40 mm
1.58”
43 mm
1.69”
43 mm
1.69”
35.5 mm
1.4”
35.5 mm
1.4”
12.6 mm
0.5”
35.5 mm
1.4”
26.5 mm
1.04”
26.5 mm
1.04”
40 mm
1.58”
23 mm
0.91”
3 mm
0.12”
M4 (4 mm deep)
Camera Top
175 mm
6.89”
