Technical Data are subject to change without notice.CAMERA DIMENSIONS – Version 2012-03
ALEXA M
Backend Top Image Plane
Backend Bottom
Optical Center
3 mm
0.12”
15 mm
0.59”
12.6 mm
0.5”
27.1 mm
1.07”
23 mm
0.91”
41.5 mm
1.63”
38.5 mm
1.52”
58.1 mm
2.29”
55 mm
2.17”
40 mm
1.58”
88.8 mm
3.5”
180 mm
7.09”
183 mm
7.2”
230 mm
9.06”
264 mm
10.39”
322.1 mm
12.68”
27 mm
1.06”
27 mm
1.06”
18 mm
1.71”
18 mm
1.71”
40 mm
1.58”
40 mm
1.58”
43 mm
1.7”
43 mm
1.7”
59 mm
2.32”
65.5 mm
2.58”
74.8 mm
2.94”
M4 (4 mm deep)
26.5 mm
1.04”
26.5 mm
1.04”
67 mm
2.64”
49.3 mm
1.94”
35.5 mm
1.4”
35.5 mm
1.4”
UNC 3/8“–16 (10 mm deep)
152.4 mm
6.0”
80 mm
3.15”
72.4 mm
2.85”
