Technical Data are subject to change without notice.CAMERA DIMENSIONS – Version 2012-03
ALEXA Studio
ALEXA Studio Length Width Height Weight
Body, SxS Module 364 mm - 14.33” 177 mm - 6.97” 163 mm - 6.42” 8.0 kg - 17.6 lb
Body, SxS Module, Camera Center Handle (CCH-1), Optical Viewfinder OVF-1
402 mm - 15.9” 268 mm - 10.55” 241 mm - 9.49” 10.2 kg - 22.5 lb
Camera Right Image Plane
Camera Front Optical Center
Optical Center
M6 (3.5mm deep)
105 mm
4.13”
134 mm
5.28”
22.8 mm
0.9”
229 mm
9.02”
12 mm
0.47”
66 mm
2.6”
163 mm
6.42”
112 mm
4.41”
156 mm
6.14”
206 mm
8.11”
138 mm
5.43”
59.4 mm
2.34”
10 mm
0.39”
50 mm
1.97”
76.2 mm
3”
265 mm
10.43”
UNC 3/8“–16 (10 mm deep)
