Technical Data are subject to change without notice.CAMERA DIMENSIONS – Version 2012-03
ALEXA Studio
364 mm
14.33”
Camera Top Image Plane
Camera Top
Optical Center
67 mm
2.64”
72 mm
2.83”
103 mm
4.06”
230 mm
9.06”
183 mm
7.21”
180 mm
7.09”
88.8 mm
3.5”
55 mm
2.17”
38.5mm
1.52”
43 mm
1.69”
43 mm
1.69”
35.5 mm
1.4”
35.5 mm
1.4”
12.6 mm
0.5”
35.5 mm
1.4”
26.5 mm
1.04”
26.5 mm
1.04”
23 mm
0.91”
M4 (4 mm deep)
175 mm
6.89”
