*XT = function available on ALEXA XT/XR only *ANAMORPH = requires Anamorphic Desqueeze License *DNxHD = requires DNxHD License *HS = requires
High Speed License *PLUS = ALEXA PLUS only *PLUS 4:3 = ALEXA PLUS 4:3 only *STUDIO = ALEXA STUDIO only *M = ALEXA M only *NON XT = only
available on ALEXA „Classic“ cameras *OG = settings and values introduced by the Open Gate Mode are not covered by this overview.
SUP 9.0
MENU
continued on next page
PROJECT menu
Sensor Mode*
XT/STUDIO/M/PLUS 4:3
(16:9/4:3/OPEN GATE)
*OG
Rec. resolution (Menu > Recording > INTERNAL)
Codec (Menu > Recording > INTERNAL)
Project frame rate (23.976/24/25/29.97/30fps)
Camera index (A-Z)
Next reel count (001-999)
Production info >>
Production
Prod. Company
Director
Cinematographer
Camera Operator
Location
Scene
Take
User Info 1/2
SYSTEM menu
Sensor >>
Sensor mode*
ALEXA XT/STUDIO/M/PLUS 4:3
(16:9/4:3)
Sensor temperature (Standard/High humidity)
Mirror image horizontal (On/Off)
Power >>
BAT1 (Plug) warning (10.0-30.0V; 21.0V)
BAT2 (Onboard) warning (10.0-30.0V; 12.0V)
External sync >>
Eye index (L/R)
Sensor sync (Off/EXT master/EXT slave)
HD out phase (+/-30 clocks; 0 clocks)
Send HD sync trigger >
Settings sync (Off/ETH master/ETH slave)
Test signal >>
Color bar (On/Off)
Enable test tone (On/Off)
Test tone level (0 dBFS/-9 dBFS/-18 dBFS)
Display + beeper >>
Display button brightness (0-8)
Button brightness (Off/Low/Medium/High)
Run beeper mode (Off/Start/Stop/Start+Stop)
System time + date >>
set date, time, timezone and daylight saving time
Fan mode (Regular/Rec low)
Network access read-only (On/Off) card >>
SD card >>
Format + prepare SD card
Prepare SD card
Firmware >>
Select update file >>
Licensed features >>
install/delete licenses; save hardware info
