ARRI SkyPanel User Manual

To Power the SkyPanel
26
The product has a 4-pin XLR male connector for battery power
and DMX data input. The pin-out is:
IMPORTANT! Check that the pin-out of the battery
pack matches the pin-out of the product. Wrong
assigned pin-outs damage the SkyPanel and / or the
battery pack.
Always follow the safety information for the battery pack. Use
only battery packs that meet all requirements listed above. The
use of battery packs that do not fulfill the requirements damage
the product and / or the battery pack.
Note: The SkyPanel switches off when the battery voltage
drops below 22 V=. The product will be damaged, when the
battery voltage exceeds 45 V=.
To Insert and Remove the 4-pin XLR Cable Connector
To insert the 4-pin XLR cable connector:
• The main switch of the battery pack must be turned off,
if possible.
• Align the raised key of the cable connector with the keyway of
the input socket (see Figure 3 on page 17). Insert the cable
connector without force in the input socket.
• The cable connector must lock. Repair or replace cable con-
nectors that do not lock.
To remove the 4-pin XLR cable connector:
• Switch of the battery pack, if possible.
• Press down the locking pin of the cable connector and remove
the cable connector.
Tips for the use of Battery Packs
It is not possible to calculate the operating time of the battery
pack exactly. The operating time is dependent from age, state
of charge, type of the battery pack and use of the SkyPanel.
Pin Assignment
1 0 V
2 n.c.
3 n.c.
4 + 23 V - 36 V=

ARRI SkyPanel Specifications

General

Type	LED Soft Light
Color Temperature	2800K - 10000K
CRI	≥ 95
Dimming	0 - 100%
Control	DMX, Ethernet
Input Voltage	100-240V AC, 50/60Hz
