ARRI SkyPanel User Manual

Fixture Menu
38
Fixture Menu
From firmware version 2.0
Note: Open and close the fixture menu the MENU button. BACK closes a sub menu and aborts an action.
Rotate INTENSITY / SELECTOR to scroll. Press INTENSITY / SELECTOR to select an item
Level 1 Level 2 Level 3 Level 4 Explanation (default setting = bold)
DMX Settings
DMX Address 1 .. 512 Start address
DMX Protocol P1 .. P16 Protocol (see page 48)
DMX Loss Behavior
Hold Last Command Fixture holds the last received control values
Black Out Fixture douses the dimmer
Hold 2 Min Fade Out Hold the last received values for 2 min. then douse
DMX Protocol Version Version x.y Version of the DMX protocol
Fan Mode
Low Fan Speed Low fan speed, silent operation
Vari Fan Speed Temperature regulated fan speed
High Fan Speed High fan speed, best cooling
Light Mode
CCT
White light, color temperature and green / magenta
correction adjustable
HSI Colored light, hue and saturation adjustable
GEL
GEL mode, gel library available, color temperature
3.200 K or 5.600 K

ARRI SkyPanel Specifications

General

Type	LED Soft Light
Color Temperature	2800K - 10000K
CRI	≥ 95
Dimming	0 - 100%
Control	DMX, Ethernet
Input Voltage	100-240V AC, 50/60Hz
