ARRI SkyPanel User Manual

Protocol
48
Protocol
Protocol V4.1 is set as default. Use the ALSM to change to Pro-
tocol V3.4. ARRI recommends to reserve 4 channels more for
each fixture when using Protocol V3.4. This way you do not
need to change the patch when you want to use additional fea-
tures which will become available with Protocol V4.1.
The Protocol V4.1 uses 4 Channels more.
SkyPanel-RP
From Firmware-Version 2.0
Mode 1: 8 bit Resolution per Function
Mode 2: 16 bit Resolution per Function
Modus 3: Coarse / Fine per Function
8 bit, 1 channel
per function
16 bit, 2 chan-
nels per function
Coarse/fine, 1-2 chan-
nels per function
Mode 1 Mode 2 Mode 3
Channel Value Percent Function
1
0-255 0-100
Dimmer
closed → open
2
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
3-5 Reserved (only V4.x)
Channel Value Percent Function
1HI
0-65.535 0-100
Dimmer
closed → open
2LO
3
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
4-6 Reserved (only V4.x)
Channel Value Prozent Funktion
1
0-255 0-100
Dimmer coarse
closed → open
2 0-255 0-100 Dimmer fine
3
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
4-6 Reserved (only V4.x)

ARRI SkyPanel Specifications

General

Type	LED Soft Light
Color Temperature	2800K - 10000K
CRI	≥ 95
Dimming	0 - 100%
Control	DMX, Ethernet
Input Voltage	100-240V AC, 50/60Hz
