Protocol
53
Mode 8: CCT & HSI, 16 bit Resolution per Function Mode 9: RGBW, 16 bit Resolution per Function
Channel Value Percent Function
1HI
0-65.535 0-100
Dimmer
closed open
2LO
3HI
0-65.535 0-100
Color temperature CCT
2.800 K 10.000 K
4LO
5 HI 0-5.000
5.001-10.000
10.001-29.999
30.000-40.000
40.001-59.999
60.000-65.535
0-7
8-15
16-46
46-61
61-92
92-100
GN saturation
neutral / no effect
full minus green
-99% -1%
neutral / no effect
1% 99%
full plus green
6LO
7HI
0-65.535 0-100
Xfade to color
white RGBW color
8LO
9HI
0-65.535 0-100
Hue
360°
10 LO
11 HI
0-65.535 0-100
Saturation
0 full saturated
12 LO
13
Reverts to
fixture set-
ting when
signal lost
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
14-16 Reserved (only V4.x)
Channel Value Percent Function
1HI
0-65.535 0-100
Dimmer
closed open
2LO
3HI
0-65.535 0-100
Intensity red
0% 100%
4LO
5HI
0-65.535 0-100
Intensity green
0% 100%
6LO
7HI
0-65.535 0-100
Intensity blue
0% 100%
8LO
9HI
0-65.535 0-100
Intensity white
0% 100%
10 LO
13
Reverts to
fixture set-
ting when
signal lost
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
12-14 Reserved (only V4.x)
