ARRI SkyPanel User Manual

Protocol
56
Mode 14: RGBW, Coarse / Fine per Function Mode 15: HSI, Coarse / Fine per Function
Channel Value Percent Function
1
0-255 0-100
Dimmer coarse
closed → open
2 0-255 0-100 Dimmer fine
3
0-255 0-100
Intensity red coarse
0% → 100%
4 0-255 0-100 Red fine
5
0-255 0-100
Intensity green coarse
0% → 100%
6 0-255 0-100 Green fine
7
0-255 0-100
Intensity blue coarse
0% → 100%
8 0-255 0-100 Blue fine
9
0-255 0-100
Intensity white coarse
0% → 100%
10 0-255 0-100 White fine
11
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
12-14 Reserved (only V4.x)
Channel Value Percent Function
1
0-255 0-100
Dimmer coarse
closed → open
2 0-255 0-100 Dimmer fine
3
0-255 0-100
Hue coarse
0 → 360°
4 0-255 0-100 Hue fine
5
0-255 0-100
Saturation coarse
0 → full saturated
6 0-255 0-100 Saturation fine
7
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
8-10 Reserved (only V4.x)

ARRI SkyPanel Specifications

General

Type	LED Soft Light
Color Temperature	2800K - 10000K
CRI	≥ 95
Dimming	0 - 100%
Control	DMX, Ethernet
Input Voltage	100-240V AC, 50/60Hz
