ARRI SkyPanel User Manual

Protocol
58
Mode 16: GEL, 8 bit per function, Base channels
Channel Value Percent Function
1
0-255 0-100
Dimmer
geschlossen → offen
2 0-128
129-255
0-50
51-100
Color temperature CCT
3.200 K
5.600 K
3
0-128
129-255
0-50
51-100
Color Matching
Best Color
Color quality optimized
Brightest
Color brightness opt.
4
0-128
129-255
0-50
51-100
Gel manufacturer
Category on ch. 5
Gel on ch. 6
Rosco
LEE Filters
5
0-50
51-101
102-152
153-203
204-255
0-20
21-39
40-60
61-80
81-255
Gel category
Manufacturer on ch. 4
Category 1:
Rosco: Color Correction
LEE: Color Correction
Category 2:
Rosco: CalColor
LEE: Color Filters
Category 3:
Rosco: Storaro Selection
LEE: 600 Series
Category 4:
Rosco: Cinelux
LEE: Cosmetic Filters
No function
Kanal Wert Prozent Funktion
6
0-255 0-100
Gel
See tables below
7
Reverts to
fixture set-
ting when
signal lost.
0-9
10-60
61-120
121-180
181-250
251-255
0-4
5-23
24-47
48-70
71-98
99-100
Fan Control
No function
Low
Variable
High
Fan max. speed
Fan off
8-10 Reserved (only V4.x)

ARRI SkyPanel Specifications

General

Type	LED Soft Light
Color Temperature	2800K - 10000K
CRI	≥ 95
Dimming	0 - 100%
Control	DMX, Ethernet
Input Voltage	100-240V AC, 50/60Hz
