3 Position the Telephony Modem over the battery, aligning the slots on the
battery bay with the tabs on the battery. Push straight down on the Tele-
phony Modem until the battery latch clicks into place.
Note: You may need to push down gently on the front of the Telephony
Modem to latch the battery into place.
Basic and Extended Backup Battery Removal
1 Pull back the battery door latch and remove the battery door. Set the door
aside.
Latch End
