Chapter 6: Using the Data Gateway
Cable Modem Startup Sequence
US/DS Online Description
Slow Flash
(1/second)
Off Downstream acquisition in progress
On
(until
Upstream
acquisition
starts)
Off Downstream acquisition completed
Fast Flash
(3/second)
Off Upstream acquisition in progress
On
Slow Flash
(during
acquisition)
On (when
modem IP
address
obtained)
Upstream acquisition completed, ready for
service
Using the Reset Button
Use the Reset button (1), on the back of the Data Gateway, to reset the modem and
perform initialization as if you power cycled the unit. You may need to reset the Data
Gateway if you are having problems connecting to the Internet. Using this button will be
rare.
Use a pointed non-metallic object to press this button. The Reset button is recessed to
prevent accidental resets.
Release 24 STANDARD 1.3 February 2015 Touchstone DG2470 Data Gateway User Guide 31
