Menu Description
Factory
Default
PID I
The integral term of the PID loop. Will only
be available if Gain is set to PID.
0.01
PID D
The derivative term of the PID loop. Will
only be available if Gain is set to PID.
0
I Lim
I Lim sets the current limit of the
temperature controller. The limit should be
set to a value that is suitable for your Peltier
device. See Using the Current Limit below
for more details.
3A
V Lim
V Lim sets the voltage limit of the
temperature controller. See Using the
Voltage Limit below for more details.
Instrument
Rating
+ 2 Volts
T-Lo Lim
Only displayed when operating in T & Ite
Modes, T-Lo Lim is the lower temperature
limit of the active sensor. It is a duplicate of
the active sensor T Lo Lim in the Sensor
Limits menu, copied here for ease of
access.
-99°C
T-Hi Lim
Only displayed when operating in T & Ite
Modes, T-Hi Lim is the upper temperature
limit of the active sensor. It is a duplicate of
active sensor T Hi Lim in the Sensor Limits
menu, copied here for ease of access.
125°C
R-Lo Lim
Only displayed when operating in R Mode,
R-Lo Lim is the lower sensor limit of the
active sensor. It is a duplicate of the R-Lo
Lim in the Sensor Limits menu, copied here
for ease of access.
0.01kΩ
R-Hi Lim
Only displayed when operating in R Mode,
R-Hi Lim is the upper sensor limit of the
active sensor. It is a duplicate of the R-Hi
Lim in the Sensor Limits menu, copied here
for ease of access.
45kΩ
Mode
This sets the operating mode (T Mode, R
Mode, or Ite Mode) of the temperature
controller.
T Mode
