Page 18 · 5400 Series TECSource User’s Manual
Menu Description
Factory
Default
Main Sensor Menu
Active Sensor
Selects which primary sensor to be used as
feedback sensor for the control loop.
1
Sens 1
Sets the Primary 1 temperature sensor
type.
Therm
100uA
Sens 2
Sets the Primary 2 temperature sensor
type.
Disabled
Sens 3
Sets the Primary 3 temperature sensor
type.
Disabled
ThermA
The A term in the Steinhart-Hart equation
for use with primary sensors 1 & 2.
1.12924E-03
ThermB
The B term in the Steinhart-Hart equation
for use with primary sensors 1 & 2.
2.34108E-04
ThermC
The C term in the Steinhart-Hart equation
for use with primary sensors 1 & 2.
0.87755E-07
RTD A
The A term in the RTD equation for use
with primary sensors 1 & 2.
3.98480E-03
RTD B
The B term in the RTD equation for use
with primary sensors 1 & 2.
-0.58700E-06
RTD C
The C term in the RTD equation for use
with primary sensors 1 & 2.
4.00000E-12
RTD R
0
The R
0
term (in Ω) in the RTD equation
for use with primary sensors 1 & 2.
100.00
AD590 M
The slope term in the AD590 correction
equation for use with primary sensor 3.
1.00000
AD590 B
The offset term, in °C, in the AD590
correction equation for use with primary
sensor 3.
0.000
LM335 M
The slope term in the LM335 correction
equation for use with primary sensors 1
& 2.
1.00000
LM335 B
The offset term, in °C, in the LM335
correction equation for use with primary
sensors 1 & 2.
0.000
