5400 Series TECSource User’s Manual · Page 19
Menu Description
Factory
Default
Tol Time
Tolerance time is the amount of time, in
seconds, that the actual temperature must
be within the set point temperature +/- the
Tol Temp value for the unit to be
considered in tolerance.
5 seconds
Tol Temp
Tolerance temperature is a temperature
band (in °C) around the set point
temperature. When the actual temperature
is within this band for longer than the Tol
Time setting, then the unit is considered to
be in tolerance.
0.1°C
Aux Sensor Menu
Aux1
Sets the Auxiliary 1 temperature sensor
type.
Disabled
Aux2
Sets the Auxiliary 2 temperature sensor
type.
Disabled
Aux3
Sets the Auxiliary 3 temperature sensor
type.
Disabled
Aux4
Sets the Auxiliary 4 temperature sensor
type.
Disabled
ThermA
The A term in the Steinhart-Hart equation
for use with auxiliary sensors.
1.12924E-03
ThermB
The B term in the Steinhart-Hart equation
for use with auxiliary sensors.
2.34108E-04
ThermC
The C term in the Steinhart-Hart equation
for use with auxiliary sensors.
0.87755E-07
Sensor Limits Menu
T1 Lo Lim Low temperature limit for Primary Sensor 1 -99°C
T1 Hi Lim High temperature limit for Primary Sensor 1 125°C
T2 Lo Lim Low temperature limit for Primary Sensor 2 -99°C
T2 Hi Lim High temperature limit for Primary Sensor 2 125°C
T3 Lo Lim Low temperature limit for Primary Sensor 3 -99°C
T3 Hi Lim High temperature limit for Primary Sensor 3 125°C
Ax1 Lo Lim Low temperature limit for Aux Sensor 1 -99°C
