Page 20 · 5400 Series TECSource User’s Manual
Menu Description
Factory
Default
Ax1 Hi Lim High temperature limit for Aux Sensor 1 125°C
Ax2 Lo Lim Low temperature limit for Aux Sensor 2 -99°C
Ax2 Hi Lim High temperature limit for Aux Sensor 2 125°C
Ax3 Lo Lim Low temperature limit for Aux Sensor 3 -99°C
Ax3 Hi Lim High temperature limit for Aux Sensor 3 125°C
Ax4 Lo Lim Low temperature limit for Aux Sensor 4 -99°C
Ax4 Hi Lim High temperature limit for Aux Sensor 4 125°C
R-Lo Lim
Sensor low limit. Only applies to the active
Primary sensor.
0.01kΩ
R-Hi Lim
Sensor high limit. Only applies to the active
Primary sensor.
45kΩ
Analog Out Menu
Function
Selects the output function of the Analog
Output.
Disabled
Analog Set
When Function is set to Direct, sets the
output voltage of the Analog Out BNC.
0.000V
T Error
When Function is set to T Error, selects the
transfer function for generating the output
voltage as a function of the temperature
error.
0.01°C/V
T Range
When Function is set to Temperature,
selects the transfer function for generating
the output voltage as a function of
temperature.
10°C/V
Digital I/O Menu
Di1 Func
Selects the action to perform when Digital
Input 1 is true.
None
Di1 Invert Inverts the active state of Digital Input 1. No
Di2 Func
Selects the action to perform when Digital
Input 2 is true.
None
Di2 Invert Inverts the active state of Digital Input 2. No
Do1 Func
Selects what status is used to control
Digital Output 1.
Off
