5400 Series TECSource User’s Manual · Page 21
Menu Description
Factory
Default
Do1 Invert Inverts the state of Digital Output 1. No
Do2 Func
Selects what status is used to control
Digital Output 2.
Off
Do2 Invert Inverts the state of Digital Output 2. No
Relay
Selects what status is used to control the
relay.
Off
Intlk Err
Selects if an interlock error is closed
(shorted) or open.
If Open
Fan Setup Menu
Ext Fan
This selects the voltage for the auxiliary fan
power supply. See the External Fan Control
section below for more information.
Off
Ext Fan Pwr
When Ext Fan is set to Custom, this sets
the specific fan voltage from 4.0 to 12.0
volts. See the External Fan Control section
below for more information.
12.0
Ext Fan Mode
Controls when the fan operates. See the
External Fan Control section below for more
information.
Auto
Ext Fan Off
When Ext Fan Mode is set to Delay, this
setting defines the number of minutes to
delay turning off the fan after the TEC
output has been turned off. See the External
Fan Control section below for more
information.
5 minutes
Func Keys Menu
Key A
and
Key B
The Key A and Key B settings control the
action assignment for the two function
keys. See Using the Function Keys section
below for additional information.
None
Communications Menu
Baud
This sets the baud rate for the RS-232 serial
port. See the Computer Interfacing Manual
which is included on the CD that
accompanied this product.
9600
