5400 Series TECSource User’s Manual · Page 23
Menu Description
Factory
Default
Tlo Limit
Turns off the TEC output if the TEC exceeds
the temperature low limit
Yes
Sensor Open
Turns off the TEC output if the sensor
appears to be an open circuit
Yes
Sensor Short
Turns off the TEC output if the sensor
appears to be a short circuit
Yes
Apply
Nonactive
If Yes, output off settings include non-active
primary sensors
No
Apply Aux
If Yes, output off settings include auxiliary
sensors
No
R Limit
Turns off the TEC output if the TEC exceeds
the sensor limit
No
Out of Tol
Turns off the TEC output if the TEC is out of
tolerance
No
ITE Limit
Turns off the TEC output if the TEC hits the
current limit
No
TEC Open
Turns off the TEC output if the TEC module
appears to be an open circuit
Yes
AutoTune PID Menu
See Using the AutoTune Function section
for more information.
Advanced Menu
T Rate
Selects a desired temperature ramp rate in
degrees Celsius per minute. Set to
0.0°C/min to disable rate limiting.
0.0°C/min
Tset Step
Adjusts the increment of the temperature
set point from 0.001°C to as much as 10°C
per knob tick.
0.001°C
H/C Mode
This selects the heating and/or cooling
mode of the TECSource. See the Resistive
Heaters and Heat/Cool Only Modes section
for more information.
Heat/Cool
