Package Manager
Install and manage BSP.
Generate report
Generate a project report (.pdf).
Recent design
Display recent projects.
 Language
English
Select English as the display language.
Chinese
Select simplified Chinese as the display language.
 Generate code
After the peripheral parameters and clock are configured as needed, click on “Generate
code” to select the project location and generate the corresponding project file.
 Help
Open manual
Open the user manual.
New version download
Download the new version online.
Go to Artery home page
Open browser to visit the official website of Artery.
Version
View the current version.
4.1.2 Toolbar
: Select English as the display language.
: Select simplified Chinese as the display language.
: Reset. Reset all peripheral parameters, pins and clock.
: Generate code. Open “Project Manager” window and generate the corresponding code. Refer
to Section 4.5.
: Visit the official website of Artery.
: Display the current MCU model.
Pin out configuration
Pin out configuration: Configure pins and parameters of MCU peripherals.
It contains the “Peripherals”, “Mode and Configuration” and “Pin layout” windows. Users can adjust
the window size as follows: hover the mouse over the window border and then a two-way arrow
appears; then, hold down the left mouse button and move to expand or shrink the window size.
4.2.1 Peripherals
The “Peripherals” window displays a list of available peripherals and middleware for the selected
MCU model. The icon in front of peripheral name indicates the peripheral configuration status.
Table 1. Peripheral status
Icon
Status
Description
Not configured
Mode and parameters are not configured.
Configured successfully
Mode and parameters are configured successfully.
