Appendices
60
Edit
Settings
Menu
Group
Submenu
items
Description
Type
Range
Default
Value
RMS Current
2
Display
only
N/A
N/A
RMS Current
3
Display
only
N/A
N/A
Line
frequency
Measured line
frequency
Display
only
N/A
N/A
Phase
ordering
The observed order
of the connections
relative to the V
1
input channel
Lower case voltage,
upper case current.
Display
only
N/A
N/A
Harmonic
Values
THD %
Total harmonic
distortion of the
selected input
channel
Display
only
N/A
N/A
1
st
Harmonic
%
Harmonic contents of
the selected input
channel
Display
only
N/A
N/A
3
rd
Harmonic
%
Display
only
N/A
N/A
5
th
Harmonic
%
Display
only
N/A
N/A
7
th
Harmonic
%
Display
only
N/A
N/A
9
th
Harmonic
%
Display
only
N/A
N/A
11
th
Harmonic
%
Display
only
N/A
N/A
13
th
Harmonic
%
Display
only
N/A
N/A
Signal Select
The input channel
selected for
harmonic
measurements
Edit/
Display
V
1
/V
2
/V
3
I
1
/I
2
/I
3
I
1
Harmonic calc
Switch harmonic
calculations On/Off
Edit/
Display
ON/OFF
ON
Comm.
Settings
Device
address
Networking address
Edit/
Display
1-255
0
