Appendices
61
Edit
Settings
Menu
Group
Submenu
items
Description
Type
Range
Default
Value
Baud rate
Communications bit
transfer speed
Edit/
Display
300-38400
19200
Parity
Parity check
Edit/
Display
Even/Odd
Even
Data bits
Number of bits
containing data
Edit/
Display
7/8/9
8
Stop bits
Number of bits
indicating end of
transmitted frame
Edit/
Display
1/2
2
Response
delay
Delay (in ms) before
AMU will respond to
an input command.
Edit/
Display
0 – 9
0
Motor
Settings
Nominal
voltage
Nominal motor phase
– neutral working
voltage
Edit/
Display
0.1 –
500000
VAC
230 VAC
Nominal
current
Nominal motor
working current
Edit/
Display
0.1- 30000
A
300 A
Nominal
frequency
Nominal line
frequency or most
common inverter
operating frequency
Edit/
Display
5 –
120 Hz
50 Hz
Nominal RPM
Nominal angular
speed of the motor
Edit/
Display
0 – 32000
rpm
1500
Connection
type
Motor connection
type under normal
running conditions
Edit/
Display
Star/Delta
Star
Motor serial #
Optional identifier
Edit/
Display
-
m000
Calibration
V channel 1
Calibration factors
for each input
channel sensor
Edit/
Display
0.1-
999999
1.0
V channel 2
Edit/
Display
0.1-
999999
1.0
V channel 3
Edit/
Display
0.1-
999999
1.0
I channel 1
Edit/
Display
0.1-
999999
1.0
I channel 2
Edit/
Display
0.1-
999999
1.0
