Ascon Tecnologic - K31D - OPERATING INSTRUCTIONS - PAG. 15
Group ]AL1 AL1 Alarm Parameters
Parameter Description Range Default Note
25
OAL1
Output where alarm AL1 is addressed
oFF Not active
Out1/Out2 Out3/Out4
Out2
26
PrA1
AL1 Alarm PV reference Pr1/Pr2/P1-2/P1-L Pr1
27
AL1t
AL1 Alarm type
LoAb Absolute Low
HiAb Absolute High
LHAb Absolute Band
LodE Deviation Low
HidE Deviation High
LHdE Deviation Band
LoAb
28
Ab1
AL1 Alarm functioning
0 ÷ 64
+1 Not active at power ON
+2 Delayed alarm
+4 Latched alarm
+8 Acknowledgeable
+16 Not active at Set Point change (relative alarms)
+32 Control Output shutdown at alarm intervention
0
29
AL1
AL1 Alarm threshold AL1L ÷ AL1H 0
30
AL1L
Low threshold band alarm AL1 or Minimum
set alarm AL1 for high or low alarm
-1999 ÷ AL1H -1999
31
AL1H
High threshold band alarm AL1 or Maximum
set alarm AL1 for high or low alarm
AL1L ÷ 9999 9999
32
HAL1
AL1 Alarm hysteresis
oFF Not active
1 ÷ 9999
1
33
AL1d
AL1 Alarm activation delay
oFF Not active
1 ÷ 9999 s
OFF
34
AL1i
Alarm AL1 activation in case of probe error no/yES no
Group ]AL2 AL2 Alarm Parameters
Parameter Description Range Default Note
35
OAL2
Output where alarm AL2 is addressed
oFF Not active
Out1/Out2 Out3/Out4
oFF
36
PrA2
AL2 Alarm PV reference Pr1/Pr2/P1-2/P1-L Pr1
37
AL2t
AL2 Alarm type
LoAb Absolute Low
HiAb Absolute High
LHAb Absolute Band
LodE Deviation Low
HidE Deviation High
LHdE Deviation Band
LoAb
38
Ab2
AL2 Alarm functioning
0 ÷ 64
+1 Not active at power ON
+2 Delayed alarm
+4 Latched alarm
+8 Acknowledgeable
+16 Not active at Set Point change (relative alarms)
+32 Control Output shutdown at alarm intervention
0
39
AL2
AL2 Alarm threshold AL2L ÷ AL2H 0
40
AL2L
Low threshold band alarm AL2 or Minimum
set alarm AL2 for high or low alarm
-1999 ÷ AL2H -1999
41
AL2H
High threshold band alarm AL2 or Maximum
set alarm AL2 for high or low alarm
AL2L ÷ 9999 9999
42
HAL2
AL2 Alarm hysteresis
oFF Not active
1 ÷ 9999
1
43
AL2d
AL2 Alarm activation delay
oFF Not active
1 ÷ 9999 s
oFF
44
AL2i
Alarm AL2 activation in case of probe error no/yES no
