Ascon Tecnologic - K31D - OPERATING INSTRUCTIONS - PAG. 17
Parameter Description Range Default Note
69
Prat
Power ratio 2.rEg/1.rEg 0.01 ÷ 99.99 1.00
70
tcr2
Cycle time of 2.rEg 0.1 ÷ 130.0 s 10.0
71
rS
Manual reset -100.0 ÷ 100.0% 0.0
72
SLor
Gradient of first ramp
inF Ramp not active
0.00 ÷ 99.99 units/min
InF
73
dur.t
Duration time between 2 ramp
inF Time not active
0.00 ÷ 99.59 h.min
InF
74
SLoF
Gradient of second ramp
inF Ramp not active
0.00 ÷ 99.99 units/min
InF
75
St.P
Soft-Start power -100 ÷ 100% 0
76
SSt
Soft-Start time
oFF Not active
0.1÷7.59 h.min
InF Endless
oFF
Group ]PAn User interface Parameters
Parameter Description Range Default Note
77
USrb
Funtion recalled by the key
noF No function
tune Autotune/Selftune start
oPLo Manual operation (open loop)
Aac Reset Alarm memory
ASi Alarms Acknowledge
CHSP Active Set Point selection
oFF Control in OFF mode
noF
78
diSP
Displayed Variable
Pr1 Pr1 Value
Pr2 Pr2 Value
P1-2 Pr1-Pr2 Value
Pou Control Power
SP.F Active Set Point Value
SP.o Operative Set Point value
AL1 AL1 threshold
AL2 AL2 threshold
AL3 AL3 threshold
P1-2
79
AdE
Shift value for the shift index functioning
0 OFF
1 ÷ 9999
2
80
Edit
Fast programming Active Set Points and
Alarms
SE Set Points changeable, Alarms not changeable
AE A larms changeable, Set Points not changeable
SAE A larms and Set Points changeable
SAnE A larms and Set Points not changeable
SAE
81
PASS
Password to access ConF menu
oFF Not active
0 ÷ 9999
oFF
Group ]sEr Serial Communications Parameters
Parameter Description Range Default Note
82
Add
Station address in case of serial communi-
cation
0 ÷ 255 1
83
baud
Transmissions speed (Baud rate) 1200/2400/9600/19.2/38.4 9600
84
PACS
Programmability through serial port
LoCL No (programmable only with the keyboard)
LorE Yes (programmable with the keyboard and
from serial port)
LorE
