ASL INTERCOM RRM02 - Page 58

RRM02 - Product Manual
Issue: 02 complete, approved
Page 58 of 68
Figure 28 Dimensions for Cabling Inside the Unit
(Internal wiring omitted for clarity.)
approx. 99 mm
102 mm
RADIO
MICROPHONE
RECEIVER
322 mm
160 mm
approx. 125 mm
45 mm
approx. 87 mm
45 mm
360 mm
approx. 123 mm
38 mm
approx. 48 mm
