RRM02 - Product Manual
Issue: 02 complete, approved
Page 63 of 68
15 Spare Parts
ASL Part Number Additional Information
204091 Nut
Function: Retain the blanking plug.
Location: Antenna cable entry hole at the lower face of the unit.
Manufacturer/Supplier: Farnell
Manufacturer/Supplier Part No.: 1178937
Manufacturer/Supplier Description: Locknut (M25)
206399 Blanking Plug
Function: Cable entry blanking plug.
Location: Unused cable entry holes.
Manufacturer/Supplier: RS Components
Manufacturer/Supplier Part No.: 809-116
Manufacturer/Supplier Description: Cable entry blanking plug (M25)
A0464668 Adaptor Lead – Short
Function: Short adaptor lead to connect the Microphone Receiver to the TNC
connectors on the upper face of the unit.
Location: Inside the box
Manufacturer/Supplier: Application Solutions (Safety and Security) Limited
Manufacturer/Supplier Part No.: A0464668
Manufacturer/Supplier Description: Adaptor lead A (160 mm)
A0464669 Adaptor Lead – Long
Function: Long adaptor lead to connect the Microphone Receiver to the TNC
connectors on the upper face of the unit.
Location: Inside the box
Manufacturer/Supplier: Application Solutions (Safety and Security) Limited
Manufacturer/Supplier Part No.: A0464669
Manufacturer/Supplier Description: Adaptor lead B (370 mm)
203659 Fuse
Function: Power supply fuse.
Location: +V Power supply terminal at the equipment rack.
Manufacturer/Supplier: Farnell
Manufacturer/Supplier Part No.: 1123206
Manufacturer/Supplier Description: Antisurge fuse 500 mA (glass)
205398 Relay
Function: Provide contact for equipment interface.
Location: DIN rail inside the back box (relay base).
Manufacturer/Supplier: Tyco Schrack
Manufacturer/Supplier Part No.: RTE24005
Manufacturer/Supplier Description: General purpose industrial relay
204327 Diode
Function: Protection.
Location: DIN rail inside the back box (relay base).
Manufacturer/Supplier: Tyco Schrack
Manufacturer/Supplier Part No.: RPMT00A0
Manufacturer/Supplier Description: Protective diode module
RMR02 Radio Microphone Receiver
Function: Receiver.
Location: Underneath bracket and PCB assembly.
Manufacturer/Supplier: Application Solutions (Safety and Security) Limited
Manufacturer/Supplier Part No.: RMR02
Manufacturer/Supplier Description: Radio Microphone Receiver
