ASL INTERCOM RRM02 - 10 Mechanical Dimensions

RRM02 - Product Manual
Issue: 02 complete, approved
Page 57 of 68
10 Mechanical Dimensions
Figure 27 Mechanical Dimensions
RRM02 Remote Radio Microphone Receiver
360 mm
160 mm
90 mm
110 mm
340 mm
MOUNTING HOLE
POSITIONS
(CASE BASE)
φ
6
.
5
m
m
50 mm
284 mm38 mm
(UPPER FACE)
(LOWER FACE)
45 mm
102 mm
209.3 mm
225.3 mm
241.3 mm
315 mm
BB
B
B = φ 25 mm
THIRD ANGLE PROJECTION
A A
MANUFACTURED IN THE UK
BY APPLICATION SOLUTIONS (SAFETY AND SECURITY) LTD
25 mm
10 mm
A = φ 22 mm (external)
POWER
ACTIVE
BUSY
~ 171 mm 42.3 mm
24.6 mm
