or in part without the express written permission of ASSA ABLOY Inc. is prohibited.

USING THE LATCH AND ACTUATOR GAUGE

Figure 3-2

If small side of Gauge does

not fit, remove any shims

added or adjust door to

make gap larger.

Latch & Actuator

Gauge

3.1 Installation and Adjustment of Door Stop-Strike (Continued)

Figure 3-3

If large side of Gauge

does fit, add provided shims

to bring strike closer

to tube.
