AD - APP DIRECT MODE
DRAM1 - RDIMM, RDIMM 3DS, LRDIMM, LRDIMM 3DS
DCPMM - DC PERSISTENT MEMORY
2 CPU Configuration (asymmetric population)
Modes DIMM_F2 DIMM_F1 DIMM_E2 DIMM_E1 DIMM_D2 DIMM_D1
AD
DRAM1 DRAM1 DRAM1
2 CPU Configuration (asymmetric population)
Modes DIMM_M2 DIMM_M1 DIMM_L2 DIMM_L1 DIMM_K2 DIMM_K1
AD
DRAM1 DRAM1 DRAM1
2 CPU Configuration (asymmetric population)
Modes DIMM_C2 DIMM_C1 DIMM_B2 DIMM_B1 DIMM_A2 DIMM_A1
AD
DRAM1 DRAM1 DCPMM DRAM1
2 CPU Configuration (asymmetric population)
Modes DIMM_J2 DIMM_J1 DIMM_H2 DIMM_H1 DIMM_G2 DIMM_G1
AD
DRAM1 DRAM1 DCPMM DRAM1
2 CPU Configuration with 2 DCPMM DIMMs (asymmetric population)
