Asus RS720-E9-RS12-E - SATA;SAS Backplane Cabling

194 pages

Save Page as PDF

To Next Page

To Previous Page

2-47

ASUS RS720-E9 Series

3 4

2.7 SATA/SAS backplane cabling

Without Rear Bay model

Reserved for

future expansions

Connects the data cable

connected to the motherboard

Connects the data cable connected to

the ASUS PCIE-NVME4-OCuLink card

Connects a 8-pin plug

from motherboard

PWR1

MSAS_HD2

MSAS_HD3

MSAS_HD1

OCUPCIE1

OCUPCIE3

OCUPCIE4

OCUPCIE2
