2-37

ASUS RS720-E9 Series

9. ConnecttheOCuLinkcablesfromtheASUSPCIE-NVME4-OCuLinkcardto

OCUPCIE1-4 slots on the backplane. Ensure that the cables follow the path as shown

below.

OCUPCIE4

OCUPCIE1

OCUPCIE2

OCUPCIE3
