14
Fig.6-2
Panel thickness
Plain washer
Schematic
1mm
2pcs
2mm
2pcs
3mm
1pc
4mm
1pc
5mm
0pc
Table 6-1
Hexagon bolt M6×12
Plain washer
Spring washer
1.9
12
1.6
Accessories:
Hexagon bolt··············· 2
Plain washer ··············· 4
φ11.5
