63
the IPsec VPN
Local ID Type
Select the local ID type
for the IKE negotiation
Local WANs IP
Address/FQDN
Local IP address or
domain name for the
IKE negotiation
Remote ID
Type
Select the remote ID
type for the IKE
negotiation
Remote WANs
IP
Address/FQDN
The address of remote
side IPsec VPN server
Local LAN IP
Address/
Subnet Mask
Length
IPsec local protected
subnet’s address
Remote LAN
IP Address/
IPsec remote protected
subnet’s address
