6
Getting started
Telephone base and charger installation
Telephone base installation
If you subscribe to digital subscriber line (DSL) high-speed Internet service
through your telephone line, you must install a DSL filter between each
telephone line cord and telephone wall jack. The filter prevents noise and
caller ID problems caused by DSL interference. Contact your DSL service
provider for more information about DSL filters.
If you have a 2-line wall jack, install the telephone base, as shown in
Option 1 below.
If you have separate wall jacks for each line, install the telephone base, as
shown in Option 2 on the next page.
Option 1: Installation with 2-line jack
Plug one end of the black telephone
line cord into the 2-line telephone wall
jack or a DSL filter.
Plug the large end of the telephone
base power adapter into a power
outlet not controlled by a wall
switch.
A DSL filter (not included)
is required if you have DSL
high-speed Internet service.
The DSL filter must be
plugged into the telephone
wall jack.
Route the power adapter
cord through this slot.
Plug the small end of the telephone base
power adapter into the power adapter jack
on the back of the telephone base.
Plug the other end of the
black telephone line cord into
the LINE 1/L1+L2 telephone
jack at the back of the
telephone base.
Raise the
antenna.
