5. Gas Meter Box Installation
Requirements
Dual Gas and Electric Meter Boxes – Dimension A height is set by the relevant
power authority.
Dimension A – Should be no less than 600mm and
no greater than 760mm.
Dimension B – Gas meter boxes must be installed
in a location not greater than 1,000mm behind the
Building Frontage of a dwelling.
Dimension C – The front of the box must be no less
than 125mm from the face brickwork if the box is
partially recessed into a wall.
Dimension A – Should be no less than 600mm and
no greater than 760mm.
Dimension B – Gas meter boxes must be installed
in a location not greater than 1,000mm behind the
Building Frontage of a dwelling.
Dimension C – The front of the box must be no less
than 260mm from the face brickwork if the box is
partially recessed into a wall.
Double or Triple Box for AL8 Meter
Dimension A – Must be no less than 200mm.
Dimension B – Gas meter boxes must be installed
in a location not greater than 1,000mm behind the
Building Frontage of a dwelling.
Dimension C – The front of the box must be no less
than 125mm from the face brickwork if the box is
partially recessed into a wall.
5.1.5 Multi-Unit Gas Meter Box (Partially Recessed or face mounted)
5.1.3 AL8 Dual Gas and Electric Meter Box (Partially Recessed
or Face Mounted)
5.1.4 AL12 Dual Gas and Electric Meter Box (Partially Recessed
or Face Mounted)
Figure 19 AL8 Dual Gas and Electric Meter Box
Figure 20 AL12 Combined Gas and Electric Meter Box
Figure 21 AL8 Double and Triple Gas Meter Box
23
