Figure 35 AL8 Non-Standard Gas Meter Bank Layout – Gas Meter Boxes
6.3 Banks of Gas Meters Mounted on AGA Approved Brackets
in Building Recesses
Enclosure width is to be determined from the number of gas meters to be situated in the
enclosure..
Manifold connections for bank of gas meters in gas meter boxes are recommended when
supply pipework cannot maintain underground separation distances from service pipework.
Gas meters may be installed in gas meter boxes on outside walls (if protected from vehicular
trafc):
• Gas meter boxes must be supplied and installed by the Responsible Person and mounted in
accordance with dimensions as shown in Figure 34 and Figure 35.
• Each lateral branch must be controlled by a valve (greater than three (3) gas meters).
• In all gas meter bank and enclosures, unit numbers are to be indicated in or on each gas
meter box or bracket prior to the gas connection taking place.
6. Gas Meter Banks
and Enclosures
33
