QSG_D6 CLASS_439.00_EN_01 /_2020-05-04
Default parameters of the FLOW type tests
Required times when instrument manage
automatic jigs
Time to pressurise the part under test
Time to stabilise the flow
The flow in the part must be between the
minimum and maximum reject level.
Pressure unit (bar, mbar, PSI, Pa, kPa, MPa)
Maximum level of the fill pressure
Minimum level of the fill pressure
Flow rate unit displayed:
—
SI System: ml/h, l/h, ml/s, ml/min, sccm, l/min,
m3/h
—
US System: in3/h, ft3/h, in3/min, in3/s, sccm.
Upper flow rate limit. Above this limit, the part is
considered as defective.
Lower flow rate limit. Under this limit, the part is
considered as defective.
Access to additional functions
Available outputs for external automatism
Duplicate the flow and pressure measurements
on the analogues outputs
Specific filters on flow measurement
Function to manage automatic jigs
Starts automatically when pressure reach min
pressure level
Buzzer activation configuration
Flow measurement resolution
Several automatism case depending on fail part
management
Stabilize the measurement values
During this time reject levels are not controlled
(perturbations)
Access to highest time resolution (fast test) and
auto zero time
Replace negative value per 0
Give as result, the highest flow during the test
time
