QSG_F600.415.00_EN_01 / 2019-04-16
12 / 38
Internal supply only
100 / 240 V A
C connector (J7) (option)
The
device can
be
connected to
a
100/240VAC power
supply
(option).
This connector has a ON/
OFF button.
It is mandatory to connect the device to the ground with a good link to the ground, to protect
against electric hazard or electrocution.
1
ON
0
OFF
11
13
