Safety
Warning
In addition to presenting a potential fire hazard, high voltage and high temperature can damage equipment
and cause severe injury or death. When installing or using this instrument, follow all instructions carefully and
use approved safety controls.
Electrical connections and wiring should be performed only by suitably trained personnel.
Do not locate this instrument where it is subject to excessive shock, vibration, dirt, moisture, oil or other
liquids. Safe ambient operating temperature range is 32° to 131° F (0° to 55° C).
Introduction
Precautions
Congratulations on your purchase of an Athena
®
Series 16 Single-Loop Controller. It is designed for ease of use and reliability
wherever accurate closed-loop control is required. Your Series 16 has been configured according to your ordering specifications as
either a universal process controller or a dedicated temperature controller. In addition, special functions such as a heater break alarm,
digital communications, etc., do not require you to make any internal jumper or DIP switch settings.
After following the instructions for installation, simply step through and set your desired parameters using the Series 16’s easy menu
system. The instrument may then be automatically or manually tuned to your process for optimum setpoint control. If you still have
questions or require any assistance in setting up or operating your controller, please contact your Athena representative or call our
factory.
After unpacking, inspect the instrument for any physical damage that may have occurred in shipping. Save all packing materials and
report any damage to the carrier immediately.
Approvals
E66598 Temperature Indicating and
Regulating Equipment.
E66598 Temperature Indicating and
Regulating Equipment.
