Operation
This is the menu level used for specifying initial configuration parameters before the controller is placed in
Run mode.
After changing the access code to “05” , press the Parameter/Access key to step through the various
control parameters. Available parameters will flash in the lower window display, alternating with the current
value for that parameter. To increase or decrease the value, simply press the appropriate Raise
or
Lower key, then press the key to step to the next parameter. To exit the menu at any time, press
the Mode key. Note: When programming in menu level “05”, all outputs are disabled; however, any
active alarms will remain active until the alarm condition is removed. New alarm conditions will not be
recognized.
This menu is used to set up the controller for digital communications and for recalibrating the controller. If
your Series 16 controller was ordered with the digital communications option, set these parameters next. To
access this menu level, follow the instructions previously given.
In this menu, alarms, cycle times, setpoint target time and limits are established. After changing the access
code to “03”, press the Parameter/Access key to step through the various parameters. To set or change
parameter values, follow the instructions given previously.
Gain, Rate and Reset parameters are automatically set during autotuning. However, they can be manually
adjusted by the operator. To return the controller to the Run mode, change the menu level access code
back to “00” or “01” as previously shown.
The only parameter that can be changed at this menu level is the Setpoint Value, using the appropriate
Raise or Lower key. To set or change other parameters, the operator must access another menu
level by pressing and holding the Parameter/Access key for 11 seconds.
This menu is automatically active when power is first applied. Both display windows are illuminated;
however, access is denied to all parameters. To set or change parameters,
the operator must access another menu level as instructed previously.
