8 Overall hydraulic layout
• Conguration 1: 1 heating circuit
Legend AE - Electrical back-up BT*
- Buffer tank (obligatory with Rdyn)
CC - Heating circulation pump MH - Hydraulic unit PC - Heating-cooling oor
R - Radiators (or fan convectors) Rdyn* - Dynamic radiators SA* - Room thermostat or room control unit (option/ except with Rdyn) SE - Outdoor sensor SP - Heated oor thermal safety fuse
